IC3601A214A - 50 V Isolated DC/DC Converter Module

SPECIFICATIONS:

Part No: IC3601A214A
Manufacturer: General Electric
Product Type: 50 V Isolated DC/DC Converter Module
Series: Mark II
Input Voltage Range: 24VDC to 125VDC
Output Voltage: 50V DC
Output Voltage Tolerance: ±1%
Output Current: Up to 5A
Ripple & Noise: < 50mV
Isolation Voltage: 1500V DC
Operating temperature: -30 to 55 ºC
Power Supply Voltage: 24 V dc
Board Size: 2.8 cm high x 8.6 cm
Weight: 0.45 kg
Availability: In Stock
Country of Origin: USA

FUNCTIONAL DESCRIPTION:

IC3601A214A is a 50 V Isolated DC/DC Converter Module manufactured and designed by General Electric as part of the Mark II Series used in GE Speedtronic Control Systems. It's designed to convert standard DC input voltages into a regulated 50V DC output. This module provides galvanic isolation between the input and output circuits, safeguarding sensitive control electronics from electrical noise, ground loops, and voltage transients.

FEATURES OF DC/DC CONVERTER MODULE:

The 50V Isolated DC/DC Converter Module is engineered to meet the high reliability and precision demands of GE Speedtronic control systems used in gas and steam turbine applications. It plays a pivotal role in powering control electronics while ensuring system safety and integrity under various operational conditions.

• Stable and Regulated 50V Output: Designed to deliver a precise and constant 50V DC output, even under varying load conditions or fluctuations in input voltage. This consistency is essential for powering analog I/O cards, signal conditioning circuits, and protection modules that rely on clean, regulated power.

• High Conversion Efficiency: These modules are built with high-efficiency switching technology, often achieving 85% or greater efficiency. Reduced heat dissipation ensures less thermal stress on nearby components, contributing to longer equipment life and reduced cooling requirements.

• Wide Input Voltage Range Compatibility: Compatible with multiple DC input sources such as 24VDC, 48VDC, or 125VDC, commonly found in turbine control environments. This flexibility supports integration into various Speedtronic panel configurations and auxiliary power supplies.

• Built-in Protection Mechanisms: Incorporates comprehensive protection features, including overvoltage protection, short-circuit protection, thermal shutdown, and under-voltage lockout. These features help prevent module and system-level failures.

• Compact and Modular Design: The module’s form factor is optimized for installation on control boards or within dense panel layouts. It enables quick replacement and supports modular maintenance strategies used in Speedtronic systems.

• Low Output Ripple and Noise: The converter ensures minimal ripple and electrical noise on the output line, which is critical for maintaining signal accuracy in high-precision measurement and control processes.

WOC has the largest stock of OEM Replacement Parts for GE Speedtronic Gas Turbine Control Systems. We can also repair your faulty boards and supply unused and rebuilt boards backed up with a warranty. Our team of experts is available around the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on parts and repairs, kindly contact our team by phone or email.

FREQUENTLY ASKED QUESTIONS:

What are the input and output specifications of the 50V Isolated DC/DC Converter Module?

The 50V Isolated DC/DC Converter Module typically accepts a DC input voltage ranging from 24VDC to 125VDC. The module then provides a regulated 50VDC output, ensuring a stable voltage supply to downstream components, even under fluctuating load conditions.

What types of input voltages are compatible with the 50V Isolated DC/DC Converter Module?

The 50V Isolated DC/DC Converter Module is designed to operate with a range of input DC voltages, including 24VDC, 48VDC, and 125VDC. These input voltages are common in GE Speedtronic systems, which use them to power various components such as I/O modules, relay drivers, and communication interfaces within turbine control panels.

What efficiency is expected from the 50V Isolated DC/DC Converter Module?

The efficiency of the converter is crucial to ensure minimal power loss, reduced heat generation, and optimal system performance. Under typical operational conditions, the converter achieves efficiency levels of 85% to 90%.
