IC3600AFGA1D1B - Function Generator Board

IC3600AFGA1D1B - Function Generator Board IC3600AFGA1D1B - Function Generator Board

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

IC3600AFGA1D1B - Function Generator Board is available in stock which ships the same day.

IC3600AFGA1D1B - Function Generator Board comes in UNUSED as well as REBUILT condition.

To avail our best deals for IC3600AFGA1D1B - Function Generator Board, contact us and we will get back to you within 24 hours.


Part No: IC3600AFGA1D1B
Manufacturer: General Electric
Product Type: Function Generator Board
Series: Mark II
Operating temperature: -30 to 55 ºC
Power Supply Voltage: 24 V dc
Board Size: 2.8 cm high x 8.6 cm
Weight: 0.45 kg
Availability: In Stock
Country of Origin: USA


IC3600AFGA1D1B is a Function Generator Board manufactured and designed by General Electric as part of the Mark II Series used in GE Speedtronic Control Systems. A function generator board is a versatile electronic device designed to generate various types of electrical waveforms, such as sine waves, square waves, triangular waves, and more. These boards are commonly used in electronics laboratories, testing environments, and educational settings to produce precise and controllable electrical signals for a wide range of applications. Here are some key features and components commonly found on a function generator board:

Waveform Generation: Function generator boards can produce different types of waveforms, including sine waves, square waves, sawtooth waves, and arbitrary waveforms. Users can select the desired waveform based on their specific needs.

Frequency Control: They offer the ability to adjust the frequency of the generated signal. Users can typically set the frequency in hertz (Hz) or kilohertz (kHz), allowing for a wide range of frequency values.

Amplitude Control: Function generators allow users to control the amplitude or voltage level of the output signal. This ensures that the generated waveform matches the requirements of the application.

Duty Cycle Control: In the case of square wave generation, users can often adjust the duty cycle, which is the ratio of the time the signal is high to the total period of the wave.

Arbitrary Waveform Generation: Some advanced function generator boards can create custom waveforms defined by the user. This feature is useful for simulating complex signals or for specific testing scenarios.

Output Interfaces: Function generator boards typically have output connectors, such as BNC (Bayonet Neill–Concelman) connectors, which are commonly used in electronic testing and measurement equipment.

Display and Controls: Many function generator boards have a built-in display for setting parameters like frequency, amplitude, and waveform type. They may also include buttons or a touchscreen interface for user interaction.

Modulation: Some function generators offer modulation capabilities, allowing users to modulate the output signal with other waveforms, such as amplitude modulation (AM) or frequency modulation (FM).

Synchronization: Function generators can often be synchronized with other instruments or devices in a laboratory setup to ensure precise timing and coordination.

Triggering: They may feature triggering options, enabling the generator to start or stop output based on external events or specific trigger conditions.

WOC has the largest stock of GE Speedtronic Control System Replacement Parts. We can also repair your faulty boards. WORLD OF CONTROLS can also supply unused and rebuilt backed-up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on any parts and repairs, kindly get in touch with our team by phone or email.
