330525-01 - Piezo-velocity Sensor

SPECIFICATIONS

Part Number: 330525-01
Manufacturer: Bently Nevada
Product Type: Piezo-velocity Sensor
Weight: 156 g (5.5 oz), typical
Diameter: 28 mm (1.1 in)
Height: 73.1 mm (2.88 in)
Case Material: 316L stainless steel
Country of Manufacture: USA (United States)

Functional Description

330525-01 is a Piezo-velocity Sensor manufactured by Bently Nevada. It is a part of the 3300 XL series. The Velomitor XA (eXtended Application) Sensor is a ruggedized version of Bently Nevada’s 330500 Velomitor Sensor, designed specifically to endure more extreme operational environments. Engineered with 316L stainless steel, the sensor’s robust housing ensures exceptional durability and resistance to corrosion, making it ideal for outdoor and industrial use without requiring additional protective enclosures.

Features

• Construction: 316L stainless steel case for maximum durability.
• Connector: Equipped with a specially designed weatherproof connector and cable assembly.
• Mounting: Designed for direct mounting without the need for a separate housing.
• Environmental Protection:
• Rated IP-65: Offers full protection against dust ingress and protection against low-pressure water jets.
• Meets NEMA 4X: Ensures protection against corrosion, windblown dust and rain, splashing water, and hose-directed water.
• CSA/NRTL/C Certified: Ensures the product complies with North American safety standards for electrical and electronic equipment, providing assurance of quality and safety in demanding applications.

These attributes make the sensor suitable for moist, dirty, or corrosive environments, typically found in industries such as oil & gas, power generation, petrochemical, and heavy manufacturing.

Terminal Housing for Velomitor XA Sensor

The Terminal Housing is a key accessory for the Velomitor XA Sensor, enabling proper field wiring and system integration. It allows for the termination of the Velomitor XA sensor cable into the main bulk cable system and facilitates the local connection of signal wires to monitoring equipment. Key Highlights:

• Provides organized and protected wiring for sensor integration.
• Supports up to two Velomitor XA Sensor cables per housing.
• Designed for ease of maintenance and safe signal transmission.

Our team of experts is available around the clock to support your Bently Nevada needs. Our team at WOC is happy to assist you with any of your automation requirements. Please contact us by phone or email for pricing and availability on any parts and repairs.

FREQUENTLY ASKED QUESTIONS

What is 330525-01?
It is a Piezo-velocity Sensor manufactured by Bently Nevada.

What makes the Velomitor XA Sensor different from the standard 330500 Velomitor?
The Velomitor XA (Extended Application) version features a rugged 316L stainless steel case and a weatherproof connector, making it suitable for use in harsh environments without requiring an additional protective housing.

What environmental ratings does the sensor meet?
The sensor meets IP-65 and NEMA 4X ratings when installed with a proper mating extension cable. This ensures protection against dust, moisture, and corrosion in industrial settings.
