330190-085-00-05 - Extension Cable

330190-085-00-05 - Extension Cable 330190-085-00-05 - Extension Cable

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

330190-085-00-05 - Extension Cable is available in stock which ships the same day.

330190-085-00-05 - Extension Cable comes in UNUSED as well as REBUILT condition.

To avail our best deals for 330190-085-00-05 - Extension Cable, contact us and we will get back to you within 24 hours.


Part Number: 330190-085-00-05
Manufacturer: Bently Nevada
Product Type: 3300 XL Standard Extension Cablee
Length: 8.5 metres
Country of Manufacture: USA (United States)

330190-085-00-05 is a 3300 XL Standard Extension Cable manufactured by Bently Nevada. It is used in 3300 XL 8mm proximity transducer system. The system measures both static (position) and dynamic (vibration) measurements and gives an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface. Vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements, are the system's major uses.


  • Ideal for Speed Measurements, Compression Systems, and Fluid-Film Bearing Machines
  • Applications with a Wide Temperature Range
  • Complete Unit and Cabling Interchangeability with Other Non-3300 XL Series Transducer System Components

Product Attributes

  • Cable Length: 8.5 metres (27.9 feet)
  • Cable Option: Standard cable
  • Agency Approval: Multiple Approvals

World of Controls has the most comprehensive catalog of Bently Nevada Replacement parts. Our professionals are standing by to help you with your needs. If you require any additional information, please contact WOC.



What is 330190-085-00-05?
It is a 3300 XL Standard Extension Cable manufactured by Bently Nevada.

What is the length of the cable?
The cable is of 8.5 metres in length.

What is the operating temperature of the component?
Operating temperature ranges from -51 degrees Celsius to +177 degrees Celsius.
