IS200EACFG1B - AC FE EX2100 Board

IS200EACFG1B - AC FE EX2100 Board IS200EACFG1B - AC FE EX2100 Board

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

IS200EACFG1B - AC FE EX2100 Board is available in stock which ships the same day.

IS200EACFG1B - AC FE EX2100 Board comes in UNUSED as well as REBUILT condition.

To avail our best deals for IS200EACFG1B - AC FE EX2100 Board, contact us and we will get back to you within 24 hours.

Request For Quote
Contact Us

Featured Product

SPECIFICATIONS

Part No.: IS200EACFG1B
Manufacturer: General Electric
Country/Region of Manufacture: United States
Product Type: AC Feedback EX2100 Board
Series: EX2100

The IS200EACFG1B is an AC Feedback EX2100 Board developed by GE. The Exciter AC Feedback board (EACF) in the EX2100 Excitation Control measures the exciter PPT AC supply voltage and current.

Application Data

The phase voltage output from potential transformers is measured using voltage test rings TP1-4 as follows:

  • Measure the Phase to Phase (or Line) Voltage AB between TP1 and TP2.
  • Measure Phase to Phase Voltage BC between TP3 and TP4.
  • Measure the Phase to Phase Voltage CA between TP4 and TP1.

IS200EACFG1B Board Replacement

  • Static-sensitive handling procedures should be implemented on all boards to prevent component damage caused by static electricity. When handling boards or components, use a wrist grounding strap only after they have been removed from potentially electrified equipment and are at a normally grounded workplace. Static sensitive handling procedures should be implemented on all boards to prevent component damage caused by static electricity.
  • When handling boards or components, use a wrist grounding strap only after they have been removed from potentially electrified equipment and are at a normally grounded workplace.
  • Turn off the power to the exciter, then test the board for power before touching it or any related circuits to avoid electric shock. Remove, insert, or change board connections while power is provided to the equipment to avoid equipment damage.



WOC experts are always available to help you with your GE turbine control component requirements. For more information, please contact WOC.


Frequently Asked Questions on IS200EACFG1B



What is IS200EACFG1B?
IS200EACFG1B is an AC Feedback EX2100 Board developed by GE

How many transformers does this board contain?
There are two transformers on the module.

Is this component available at WOC?
Contact WOC sales team for more information regarding the availability and price details.

What is the country of origin for the board?
The component was manufactured in United States.
