DS200DTBCG1A - TERM. BD RLY/SOLENOID

DS200DTBCG1A - TERM. BD RLY/SOLENOID DS200DTBCG1A - TERM. BD RLY/SOLENOID

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

DS200DTBCG1A - TERM. BD RLY/SOLENOID is available in stock which ships the same day.

DS200DTBCG1A - TERM. BD RLY/SOLENOID comes in UNUSED as well as REBUILT condition.

To avail our best deals for DS200DTBCG1A - TERM. BD RLY/SOLENOID, contact us and we will get back to you within 24 hours.

SPECIFICATIONS

Part Number: DS200DTBCG1A
Manufacturer: General Electric
Series: Mark V
Function: Terminal Board Relay Solenoid

DS200DTBCG1A is a Connector Relay Terminal Board and is part of the GE Speedtronic Mark V gas turbine control. The DS200DTBCGIA has two terminal blocks, each with 110 signal wire terminals. There are also two 3-wire bayonet connections and one 2-wire bayonet connector, as well as ten jumpers. The board measures 3 inches tall by 11.5 inches long. The board can be mounted inside the drive if there are enough spaces. Because the board can connect to 220 signal wires, it's critical that you put it where the signal wires can be correctly routed. Because of the potential of interference, signal wires cannot be routed near power lines.

  • The power cables are noisy, which means they emit signal noise that can degrade the precision of the signals received by the circuit board. They also obstruct the board's reception of signals. Interference can sometimes be blocked by using shielded wires.
  • However, routing the power cables independently from the signal wires is the ideal option. If they must be routed together, the duration of the run they are bundled together should be kept to a minimum. The more the current carried by a power line, the further apart the power and signal wires should be routed.
  • The signal cables should be routed so that they do not obstruct the airflow inside the drive. The drive is constructed with air vents at the bottom to allow cool air to enter the drive. The air passes over the heated components and dissipates the heat through the drive's top vents.
  • The power cables can be routed together with the fiber optic cables if fiber optic cables are routed within the drive. This is due to the fact that fiber optic cable is impervious to interference.
  • WOC has the largest stock of Speedtronic Mark V control spares and we can repair your faulty DS200DTBCG1A with a warranty of 12 months. WORLD OF CONTROLS can also supply UNUSED and REBUILT DS200DTBCG1A backed up with a warranty of 24 months.
  • Our team of experts is available round the clock to support your DS200DTBCG1A needs. Our sales team at WOC is happy to assist you with any of your automation requirements. Please contact our staff by phone or email for pricing and availability on any parts and repairs.


FREQUENTLY ASKED QUESTIONS

The DS200DTBCG1A connects to which terminal board?

Most of the solenoids linked to DS200DTBCG1A are powered by J8x cables, which connect to the DS200DTBCG1A first and then to the DTBD terminal board through a jumper.

Which of the DS200DTBCG1A plugs provides the greatest power to the solenoids?

Most of the 125 VDC solenoids linked to the DS200DTBCG1A terminal board are powered by the J8x connections.

On the DS200DTBCG1A, what are relay outputs 1-15?

On the DS200DTBCG1A, relay outputs 1-15 are either dry contact or 125 VDC for solenoids.
