IS200IGPAG1A - Gate Driver Power Supply Card

SPECIFICATIONS

Part No.: IS200IGPAG1A
Manufacturer: General Electric
Country of Manufacture: United States of America (USA)
Temperature: -30 to +65 oC
Product Type: Gate Driver Power Supply Card
Availability: In Stock
Series: EX2100

Functional Description

IS200IGPAG1A is a Gate Driver Power Supply Card developed by GE. It is a part of the EX2100 control system. Its integration directly into the Integrated Gate Commutated Thyristor (IGCT) facilitates seamless operation within the system. The component boasts a robust design featuring two coil inductors that enhance its performance and reliability. With a focus on connectivity, it is equipped with two board connectors - a 9-pin vertical header connector designated for output and a 5-pin connector tailored for input, ensuring seamless integration into the system architecture.

Features

• The board's power handling capabilities are underscored by the presence of seven high-voltage electrolytic capacitors, strategically arranged in groups of one, two, and four, to efficiently manage power fluctuations and ensure stable operation under varying conditions.
• Incorporating user-friendly visual indicators, the card features two LED strips, each comprising four LEDs, providing at-a-glance status updates and diagnostic feedback, thereby simplifying troubleshooting processes and enhancing overall system management efficiency.

Exciter Software

• The Exciter Software plays a pivotal role in the seamless operation and control of excitation systems within power generation setups. Configured and loaded from a toolbox interface, this software resides within the controllers, where it orchestrates a multitude of control functions essential for optimal system performance.
• Visualized as interconnected control blocks on the toolbox screen, the Exciter Software delineates the signal flow, providing operators with a clear overview of the system's operation. During normal operation, the AC regulator is typically selected to govern the system's behavior.
• To facilitate its operations, the software relies on input signals derived from generator voltages and currents, which are obtained from Potential Transformers (PTs) and Current Transformers (CTs). These signals are then channeled to the EPCT board, serving as a signal conditioner responsible for isolating and scaling the signals to ensure compatibility with the control system.
• Once conditioned, these signals are transmitted to the controller, where sophisticated software conversion algorithms come into play. These algorithms meticulously process the input signals to compute system variables vital for the execution of various control functions, including regulation, limitation, and protection. By leveraging these calculated variables, the software orchestrates precise control actions, ensuring the excitation system operates within designated parameters while safeguarding against potential faults or abnormalities.
• In essence, the Exciter Software serves as the intelligent backbone of the excitation system, harnessing advanced algorithms and control logic to optimize performance, maintain stability, and uphold the integrity of power generation processes.

The WOC team is always available to help you with your EX2100 requirements. For more information, please contact WOC.

Frequently Asked Questions

What is IS200IGPAG1A?
It is a Gate Driver Power Supply Card developed by GE under the EX2100 series.

What is Exciter Software?
The Exciter Software is a critical component of excitation systems utilized in power generation setups. It is responsible for controlling various aspects of the excitation process to ensure optimal performance and stability.

How is Exciter Software configured and loaded?
Exciter Software is configured and loaded from a toolbox interface, typically residing within the controllers of the system.

What is the role of Exciter Software in the excitation system?
The Exciter Software oversees key control functions, including regulation of generator field and stator currents and voltages, ensuring smooth operation and adherence to specified parameters.
