5463-561 - Analog Input Module (8-Channel, 4�20 mA)

SPECIFICATIONS:

Part Number: 5463-561
Manufacturer: Woodward
Series: MicroNet / NetCon 5000
Product Type: Analog Input (AI) Module
Channels: 8 Independent Input Channels
Input Signal Range: 4�20 mA or 0�5 Vdc (Hardware Configurable)
Resolution: 16-Bit A/D Conversion
Isolation: 500 Vrms Channel-to-Backplane
Accuracy: �0.1% of Full Scale
Update Rate: High-Speed Deterministic
Operating Temperature: -40 �C to +70 �C
Mounting: Chassis / Rack Mounted
Availability: In Stock

FUNCTIONAL DESCRIPTION:

The 5463-561 Analog Input Module is a high-performance interface designed for Woodward MicroNet and NetCon 5000 control systems. Its primary role is to receive and process analog signals from various field transmitters, such as pressure transducers, level sensors, and flow meters. By converting these continuous 4�20 mA or 0�5 Vdc signals into high-resolution digital data, the module provides the Master CPU with the real-time process variables necessary for precise turbine governance and auxiliary system management.

PRECISION AND SIGNAL FIDELITY:

For critical industrial applications, accuracy is paramount. The 5463-561 utilizes a 16-bit analog-to-digital (A/D) converter to provide exceptional signal resolution, allowing the control system to detect minute changes in process conditions. Each of the 8 channels is equipped with independent filtering to suppress high-frequency noise and electromagnetic interference (EMI). This ensures that the data reaching the controller is stable and representative of actual field conditions, preventing erratic control behavior or unnecessary process fluctuations.

INDUSTRIAL PROTECTION AND DIAGNOSTICS:

Built to withstand the rigorous environment of power plants and industrial facilities, the Analog Input Module features 500 Vrms galvanic isolation. This protects the sensitive internal backplane from field-side electrical surges and ground loops. The module also includes comprehensive onboard diagnostics that monitor each input loop for integrity. It can detect common field faults such as out-of-range signals, open loops, or hardware failures, immediately communicating these statuses to the Master CPU for annunciation or fail-safe logic execution.

AVAILABILITY AND SUPPORT:

World of Controls offers the 5463-561 Analog Input Module in both unused and professionally rebuilt conditions, providing a reliable solution for system upgrades or emergency replacements. Every module undergoes extensive functional testing to ensure it meets original manufacturer specifications and is backed by a comprehensive warranty. Our global support team is available to assist with technical inquiries, configuration guidance, and expedited shipping. Contact us today for a quote or more information on maintaining your Woodward control hardware.

FREQUENTLY ASKED QUESTIONS:

What is the Woodward 5463-561?

It is an 8-channel Analog Input (AI) module used in Woodward MicroNet and NetCon 5000 systems. It monitors process variables by converting 4�20 mA or voltage signals from field sensors into digital data for the control system.

Does the Analog Input Module support voltage inputs?

Yes, while most commonly used for 4�20 mA current loops, the Analog Input Module can be configured to accept 0�5 Vdc signals. This flexibility allows it to interface with a wide range of industrial sensing equipment.

How does the module handle a failed sensor?

The Analog Input Module features built-in diagnostics that monitor the input range. If a signal falls below a certain threshold (indicating an open circuit or sensor failure), the module flags the channel as invalid, allowing the control software to take appropriate action, such as switching to a redundant sensor.

Is software configuration required in Woodward GAP?

Yes. After physically installing the module into the rack, the input types, scaling factors, and signal ranges must be defined within the Woodward GAP (Graphical Application Programmer) software to ensure the data is correctly used by the control application.

�
