125720-02 - Relay Output Module

SPECIFICATIONS

Part Number: 125720-02
Manufacturer: Bently Nevada
Power Consumption: 6 watts typical
Product Type: Module
Availability: In Stock
Function: Relay Output Module
Country of Manufacture: United States (USA)

Functional Description

125720-02 is a relay output module developed by Bently Nevada. As a relay output module, it serves as an interface between the control system and external devices or equipment that require switching or control signals. The module features multiple relay circuits that enable the switching of electrical signals based on control commands received from the control system. Each relay within the module is capable of handling specific voltage and current levels, providing versatility in controlling various types of loads. It emphasizes the quality and reliability of their products, subjecting the module to rigorous testing and quality control procedures. This ensures its robustness, performance, and long-term reliability in industrial applications.

3500 Rack Configuration Software

• All modules of the Machinery Protection System are configured using Rack Configuration Software. All Configuration Software is Windows-based and network-capable.
• The 3500 Data Acquisition and Operator Display software serves primarily as an emulation package for displaying data normally found on the front-panel display of a machinery protection system. Basic trending and event archiving functions are also provided by the software. It lacks the dynamic data capture and plotting capabilities required for machine diagnostics or connection to a Bently Nevada Decision Support system.

Rack Configuration Computer

• Intel Pentium processor or better
• 800x600 or higher resolution Monitor
• CD-ROM drive
• 128 Megabytes of RAM recommended
• Microsoft Windows 7 or Windows 2012 Server operating system or greater
• English Operating Systems only
• Minimum 35 Megabytes of available hard disk space
• RS232 Serial Port , USB port with USB to Serial Adapter, Modem, or Network access to 3500 racks

LEDs

• OK LED: Illuminated when module is functioning properly.
• TX/RX LED: Transmit and Receive. Flashes to indicate proper communications between this module and other modules within the rack.
• CH ALARM LED: Illuminated when the Relay Channel is in an alarm state.

World of Controls has the most comprehensive selection of GE and Bently Nevada components. Our professionals are available to help you with your requirements at any time. If you require any additional information, please contact WOC immediately.

Frequently Asked Questions

What is 125720-02?
It is a Relay Output Module developed by Bently Nevada.

How are the modules of the Machinery Protection System configured?
The modules of the Machinery Protection System are configured using Rack Configuration Software. This software allows users to set up and customize the configuration of the system according to their specific needs. It provides a user-friendly interface for configuring and managing the modules.

What is the nature of the Configuration Software used for the Machinery Protection System?
The Configuration Software used for the Machinery Protection System is Windows-based and network-capable. This means that it is compatible with Windows operating systems and can be connected to a network for convenient configuration and management of the system.

What is the purpose of the 3500 Data Acquisition and Operator Display software?
The 3500 Data Acquisition and Operator Display software primarily functions as an emulation package. It replicates the data that would typically be displayed on the front-panel display of a machinery protection system. Users can view real-time data, alarms, and system status through this software.
