DS3800XTBA - Isolation Module

DS3800XTBA - Isolation Module DS3800XTBA - Isolation Module

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

DS3800XTBA - Isolation Module is available in stock which ships the same day.

DS3800XTBA - Isolation Module comes in UNUSED as well as REBUILT condition.

To avail our best deals for DS3800XTBA - Isolation Module, contact us and we will get back to you within 24 hours.


Part Number: DS3800XTBA
Manufacturer: General Electric
Series: Mark IV
Product Type: Isolation Module
Operating temperature: -35 to 65 degrees Celsius
Power Supply Voltage: 125 V dc
Technology: Surface Mount
Board Size: 33.0 cm high x 17.8 cm
Size: 8.25 cm high x 4.27 cm
Repair: 3-7 Day
Availability: In Stock
Weight: 2 lbs
Country of Origin: United States


DS3800XTBA is an Isolation Module manufactured and designed by General Electric as part of the Mark IV Series used in GE Speedtronic Gas Turbine Control Systems. It serves as a terminal board card. It is designed for use in industrial control systems and is manufactured by GE, a global leader in the field of electrical and electronic engineering.


  • This isolation module plays a critical role in electrical power transmission and distribution systems, where it is used to provide electrical isolation between different parts of the system. This helps to ensure that electrical faults, such as short circuits, do not cause damage to other components in the system.
  • The isolation module is designed to be easy to install and maintain. It features a compact and modular construction, which allows for quick and easy replacement of individual components if needed. This helps to reduce downtime and minimize the cost of maintenance.
  • The terminal board card also features high-quality components and advanced circuitry, which ensures that it operates with maximum efficiency and reliability in demanding industrial environments. It is engineered to withstand extreme temperatures, humidity, and other environmental conditions, and is designed to provide long-term performance and durability.
  • The routing of the wire connected to the bottom of the dashed oval symbol defines the termination of the shield drain wire.
  • The shield for the portion of the shielded wire between the jack connectors and the IO module is terminated at the shield bus bar in the IO module in the example on sheet 27B.
  • At a junction box, shields for wiring routed through jack connectors are jumpered together. This collection of shields is then connected to one of the jack pins, usually the last jack pin. Sheet 44E of the elementary shows the connection of the shield drain wire from the last pin in the cable.

WOC maintains the largest inventory of replacement parts for GE Speedtronic control systems. Additionally, we offer warranty-backed unused and rebuilt boards as well as board repairs for your damaged ones. For your OEM needs, our team of professionals is available around the clock. We at WOC are happy to help you with any needs you may have in terms of automation. Please contact our team by phone or email for pricing and availability on any components and repairs.


What is the purpose of the component?

The purpose is to provide electrical isolation between different parts of the electrical power transmission and distribution system to prevent electrical faults from causing damage to other components.

What are the features of the Isolation Module?

It features a compact and modular construction for easy installation and maintenance, high-quality components and advanced circuitry for efficient and reliable operation, and durability to withstand extreme environmental conditions.
