Ds3800hmac Media Access Unit

DS3800HMAC - Media Access Unit

DS3800HMAC - Media Access Unit DS3800HMAC - Media Access Unit

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

DS3800HMAC - Media Access Unit is available in stock which ships the same day.

DS3800HMAC - Media Access Unit comes in UNUSED as well as REBUILT condition.

To avail our best deals for DS3800HMAC - Media Access Unit, contact us and we will get back to you within 24 hours.

Request For Quote
Contact Us

Featured Product

SPECIFICATIONS

Part Number: DS3800HMAC
Manufacturer: General Electric
Series: Mark IV
Product type: Media Access Unit
Availability: In Stock
Country of Manufacture: United States (USA)

DS3800HMAC is a media access unit developed by GE. It is a part of Mark IV control system. It serves as a media access unit that controls how data travels between other components. Along its back edge, the device includes right-angled pin connectors and stab-on connectors.

System Testing

  • There are four stages to the Mark IV hardware production testing: components, cards, modules, and panels. All integrated circuits undergo three tests as part of the component test: a temperature cycle, a hermetic seal fine and gross leakage test, and a burn-in test. Then, a 100% electrical parameter test is performed on the ICs. Printed wire boards (cards) are subjected to an in circuit test, followed by a functional test, after being burned in at 155F for 160 hours with the electricity on. If additional calibration is needed, it is carried out after the testing separately. A General Radio GR2270 tester is now undergoing in-circuit and functional testing. The exams are completely automated, providing a high level of precision and consistency.
  • Individual tests are performed on each module, ranging from visual inspections of basic backplanes through automatic wiring scans of wired backplanes and cables to complete functional testing of power supplies. The C communicator and the RST controller modules' entire hardware setup will be functionally tested. A functional hardware test is performed on the completely constructed panel, simulating all input signals and verifying all output signals. The customer interfaces are used in the testing and measurements for completeness. The testing is completely planned, which provides a high level of confidence in the accuracy and caliber of the tests.

WOC is happy to assist you with any of your GE requirements. Please contact us by phone or email for pricing and availability on any parts and repairs.

FREQUENTLY ASKED QUESTIONS

What is DS3800HMAC?
It is a media access unit developed by GE.

What are the four stages of the Mark IV hardware production testing?
The four stages of the Mark IV hardware production testing are components, cards, modules, and panels.

What tests are performed during the component test stage?
During the component test stage, integrated circuits undergo a temperature cycle, a hermetic seal fine and gross leakage test, and a burn-in test. Additionally, a 100% electrical parameter test is performed on the ICs.

What tests are performed during the card test stage?
During the card test stage, printed wire boards (cards) are subjected to an in circuit test, followed by a functional test after being burned in at 155F for 160 hours with the electricity on. If additional calibration is needed, it is carried out after the testing separately.
