DS3800XTIA1A1B - I/O CIRCUIT BOARD

SPECIFICATIONS

Part No.: DS3800XTIA1A1B
Manufacturer: General Electric
Product Type: I/O Circuit Board
Series: Mark IV

DS3800XTIA1A1B is an Input-Output circuit board developed by General Electric under the Mark IV series. Gas and steam turbines provide a quick and flexible source of energy. A gas turbine creates pressure by turning turbine blades with a mixture of gases created by combining air and fuel in an internal combustion engine.

• A steam turbine is powered by a big water-filled boiler. After that, the boiler is heated to produce a massive volume of steam, which turns the turbine blades. The spinning turbine blades generate energy, which is then used for other purposes.
• One variable resistor, commonly known as a potentiometer, is included in the board. A little screw on the top of the variable resistor allows you to modify the resistance.
• The PCB includes two sets of jumper ports, each of which has a cover and controls the flow of electricity across the circuit board. Thirty yellow LEDs, one yellow diode, and two other diodes make up the board. Three big black female terminal ports are available on the PCB.
• There are twelve golden ports on each female terminal port. The board has a black male terminal port that is medium in size. These are used to connect the component to other circuit boards.

World of Controls has the most comprehensive selection of GE Speedtronic Mark IV control components. At any time, our experts are accessible to help you with your Mark IV obligations. Please contact WOC as soon as possible if you require any extra information.



Frequently Asked Questions



What is DS3800XTIA1A1B?
DS3800XTIA1A1B is an Input-Output circuit board developed by General Electric under the Mark IV series.

How to Obtain DS3800XTIA1A1B?
World of Controls provides DS3800XTIA1A1B as well as other turbine control products. Contact WOC.
