336A3435BMG01

336A3435BMG01 - Ribbon Cable

336A3435BMG01 - Ribbon Cable 336A3435BMG01 - Ribbon Cable

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

336A3435BMG01 - Ribbon Cable is available in stock which ships the same day.

336A3435BMG01 - Ribbon Cable comes in UNUSED as well as REBUILT condition.

To avail our best deals for 336A3435BMG01 - Ribbon Cable, contact us and we will get back to you within 24 hours.

Request For Quote
Contact Us

Featured Product

SPECIFICATIONS

Part No.: 336A3435BMG01
Manufacturer: General Electric
Country of Manufacture: United States of America (USA)
Product Type: Ribbon Cable
Availability: In Stock
Series: Mark V

Functional Description

336A3435BMG01 is a Ribbon Cable developed by GE. It is a part of the Mark V control system.This ribbon cable is a vital component of the Mark V control architecture, facilitating seamless interconnection between control boards, I/O modules, and processor cards.

Features

  • Function: Serves as an internal communication cable between circuit boards/modules within the Mark V control cabinet.
  • Cable Type: Ribbon cable with multiple conductors in a single plane, suitable for compact and organized internal wiring.
  • Connector Interface: Factory-terminated with edge or IDC (Insulation Displacement Connector) compatible connectors (specific to application).
  • Signal Support: Designed for multi-channel digital signal transmission between microprocessor boards, terminal boards, and I/O modules.
  • Electrical Performance: Supports TTL/CMOS-level signals. Maintains signal integrity in environments with electromagnetic interference (EMI)
  • Mechanical Characteristics: Flexible, low-profile construction for tight cabinet routing
  • Pitch: standard 0.050 inch (1.27 mm) conductor spacing (typical for GE ribbon cables)
  • Insulation: PVC or equivalent thermoplastic, rated for industrial control environments
  • System Integration: Used in the Mark V’s triple-redundant controller system, supporting SIFT architecture by linking R S and T controllers, I/O terminal boards, and Protective and communication modules.
  • Operating temperature: -20°C to +60°C (typical for control cabinet use)
  • Designed for enclosed control panel installations; not intended for external field use
  • Certifications: Compliant with GE Mark V system quality and reliability standards

The WOC team is always available to help you with your Mark V requirements. For more information, please contact WOC.

Frequently Asked Questions

What is 336A3435BMG01?
It is a Ribbon Cable developed by GE under the Mark V series.

What kind of signals does the ribbon cable carry?
It transmits digital control signals, typically TTL/CMOS-level, between various boards such as the R, S, T processors, and I/O interfaces.

Is the cable shielded or armored?
No, this ribbon cable is not shielded or armored. It is designed for internal use within control cabinets where electromagnetic interference is minimized.
