330980-50-00 - NSv Proximity Sensor

Specifications

Part Number: 330980-50-00
Manufacturer: Bently Nevada
Country of Manufacture: United States (USA)
Product Type: Proximity Sensor
Total Length: 5.0 mSystem Length
Mounting Option: Panel Mount
Series: Bently Nevada 3300

330980-50-00 is an NSv Proximity Sensor developed by Bently Nevada. It is a part of the Bently Nevada 3300 series. For use with centrifugal air compressors, refrigeration compressors, process gas compressors, and other equipment requiring precise installation, Bently Nevada 3300 XL NSv Proximity Transducer System is designed. The 3300 XL NSv Transducer System is primarily used in locations where regular Bently Nevada 3300 and 3300 XL 5 and 8 mm Transducer Systems cannot be used due to counterbore, side view, or rearview constraints. It is also perfect for applications involving small targets, including monitoring radial vibration on shafts under 51 mm (2 in) or axial position on flat targets under 15 mm (0.6 in).

330980-50-00 Features

• The 3000-series or 7000-series 190 Transducer System and the 3300 RAM Transducer Systems can both be replaced thanks to the 3300 XL NSv Transducer System's architecture. The existing probe, extension cable, and monitoring system with 3300 XL NSv Proximitor Sensor may be used to upgrade the 3300 RAM system to the 3300 XL NSv system. For upgrades from the 3000-series or 7000-series transducer systems, NSv components must be used in place of the probe, extension cable, and proximity sensor.
• The most typical output for eddy current transducers has an average scale factor of 7.87 V/mm (200 mV/mil), found in the 3300 XL NSv Transducer System. Its linear range is less than that of the Bently Nevada 3300 XL-series 5 and 8 mm Transducer System because of its improved side-view and tiny target features. With The linear range of the 1.5 mm (60 mils) transducer system is greater than that of the 3000-series 190 transducer system.

Configuration

• Total Length and Mounting Option: 5.0 m (16.4 f) System Length, Panel Mount
• Agency Approval Option: Not Required

Characteristics

• For use in Tight Installation needs
• Replaces 3300 RAM Transducer Systems and 3000-Series or 7000-series 190 Transducer System
• Average Scale Factor of 7.87 V/mm (200 mV/mil)

World of Controls has the most extensive stock of Bently Nevada spares. WOC is available round the clock to support your urgent needs related to critical spares, contact us.



Frequently Asked Questions



What is Bently Nevada 330980-50-00?
330980-50-00 is an NSv Proximity Sensor developed by Bently Nevada under Bently Nevada 3300 series.

What is the mounting option?
The component can be Panel Mounted

How to obtain 330980-50-00?
Contact World for Controls for Bently Nevada spare parts. We supply worldwide.
