330104-00-12-10-02 - Proximity Probe

SPECIFICATIONS

Part Number: 330104-00-12-10-02
Manufacturer: Bently Nevada
Product Type: Proximity Probe
Operating Temperature : -35oC to +85oC
Storage Temperature : -51oC to +100oc
Thread Type: M10 x 1
Armored Cable: Yes
Case Length: 120 mm
Country of Manufacture: USA (United States)

Functional Description

330104-00-12-10-02 is a Proximity Probe manufactured by Bently Nevada. It is a part of 3300 XL series. It is engineered to deliver accurate, reliable, and robust non-contact measurements of shaft position and vibration. Known for its proven field reliability, this model is designed for industrial applications requiring precise monitoring of rotating machinery.

Product Overview

• Thread Type: M10 x 1
• Armor: Yes (Armored Cable for Enhanced Protection)
• Unthreaded Length: 0 mm
• Overall Case Length: 120 mm
• Total Cable Length: 1.0 metre (3.3 feet)
• Connector Type: Miniature coaxial ClickLoc® connector with standard cable
• Agency Approval: Not required

System Compatibility

This probe is a core component of the 3300 XL 8 mm Proximity Transducer System, which includes:

• One 3300 XL 8 mm Proximity Probe
• One 3300 XL Extension Cable
• One 3300 XL Proximitor Sensor

Together, the system provides an output voltage proportional to the gap between the probe tip and a conductive target surface, typically the rotating shaft of a machine. The system enables both static (position) and dynamic (vibration) measurements.

Features

• Precision Monitoring: Designed to deliver highly accurate measurements critical to machine protection and predictive maintenance systems. Ideal for detecting shaft movement, misalignment, unbalance, and mechanical looseness.
• Robust Armored Design: Features a durable armored cable to protect against mechanical damage, wear, and harsh environmental conditions. Suitable for high-vibration and industrial environments.
• ClickLoc Connector: Comes with a miniature coaxial ClickLoc connector, ensuring a secure and reliable connection that resists loosening due to vibration or handling. Simplifies installation and maintenance.
• Threading and Installation: Threaded with M10 x 1, allowing easy and secure installation into compatible mounting locations. Overall case length of 120 mm provides flexibility in mounting depth and target reach.
• Total Length and Flexibility: The 1.0-meter cable length supports close-range connections within machinery cabinets or systems with limited routing requirements.

Our team of experts is available round the clock to support your Bently Nevada needs. Our team at WOC is happy to assist you with any of your automation requirements. Please contact us by phone or email for pricing and availability on any parts and repairs.

FREQUENTLY ASKED QUESTIONS

What is 330104-00-12-10-02?
It is a Proximity Probe manufactured by Bently Nevada.

What is the thread type and size for this probe?
This probe uses an M10 x 1 thread, designed for precise and secure mounting in compatible housings or brackets.

Is the cable armored?
Yes, this model comes with armored cable, which protects against abrasion, mechanical damage, and harsh environments.

What is the total length of the probe cable?
The probe has a total cable length of 1.0 metre (3.3 feet), ideal for short to moderate-distance connections.
