DS200TBQDG1AEE - TERM BD (R-S-T) EXT

SPECIFICATIONS

Part Number: DS200TBQDG1AEE
Manufacturer: General Electric
Series: Mark V
Product Type: RST Extension Termination Board

Two terminal blocks are included on the GE RST Extension Analog Termination Board DS200TBQDG1AEE. Each block comprises 107 signal wire terminals. Multiple test points, two jumpers, and three 34-pin connections are also included on the GE RST Extension Analog Termination Board DS200TBQDG1AEE. A qualified servicer can use the three test points on the GE RST Extension Analog Termination Board DS200TBQDG1AEE to test the board's individual circuits.

• Individual IDs for the test points are TP1, TP2, and TP3. The testing equipment must be qualified for the purpose and completely calibrated to test the circuit's functionality before the test points may be tested. All probes connected to it must be compatible with the tester, and the instrument's settings must be appropriate for the purpose.
• You can utilize the diagnostic tools included with the drive if the testing instrument does not detect a definitive problem with the board. The diagnostic tools are accessed via the drive's keypad. It can also be utilized by an operator to alter the drive's behavior.
• The motor can be stopped or started by the operator. The operator can also modify the motor's direction as well as its speed. The keypad's keys are labeled to indicate the action that occurs when you press the key. Some keys will take you to a user interface where you can access the diagnostic tools. A menu of activities is available in the user interface.
• WOC has the largest stock of Speedtronic Mark V control spares and we can repair your faulty DS200TBQDG1AEE with a warranty. WORLD OF CONTROLS can also supply UNUSED and REBUILT parts backed up with a warranty.

Our team of experts are available round the clock to support your DS200TBQDG1AEE needs. Our sales team at WOC is happy to assist you with any of your automation requirements. Please contact our staff by phone or email for pricing and availability on any parts and repairs.



FREQUENTLY ASKED QUESTIONS



How many terminal blocks are included in DS200TBQDG1AEE?

Two terminal blocks are included on the GE RST Extension Analog Termination Board DS200TBQDG1AFF. Each block comprises 107 signal wire terminals.

On the DS200TBQDG1AEE, what are the termination signals?

Proximitors, LVDT input signals, and milliamp outputs are the termination signals on the DS200TBQDG1AEE.

How to obtain DS200TBQDG1AEE?

WORLD OF CONTROLS supply UNUSED and REBUILT DS200TBQDG1AEE backed up with a warranty.
