DS200TCTSG1AFE - Simplex Trip Board

SPECIFICATIONS

Part Number: DS200TCTSG1AFE
Manufacturer: General Electric
Series: Mark V
Product Type: Simplex Trip Board

There are 12 plug-in relays on the GE Simplex Trip Board DS200TCTSG1AFE. There are additionally three 16-pin and two 12-pin connectors. JDR, JDS, and JDT are the IDs allocated to the 16-pin connectors. JN and JM are the IDs assigned to the 12-pin connectors. In a high-voltage drive, the GE Simplex Trip Board DS200TCTSG1AFE is installed.

• Working around it and performing installation and service functions should only be done by trained people. An electric shock or a severe burn might result from improper handling. It can potentially start a fire or cause other significant problems.
• Concerns about the powerful motor and other moving parts are also present. Damage to the motor assembly or other components can occur if a screw or other metal object is jammed into the motor.
• The first step is to turn off the power. Power is supplied to the drive via a power supply. The power supply can be turned off by an electrician or installer who is familiar with the installation. The fuse is usually removed to accomplish this. Keep the fuse close by and in a secure location.
• The drive's power cabling must meet all national and local regulations. This is true for both the cable type and the cable routing. Because high-voltage electricity might cause interference, power lines must be routed separately from signal wires.
• If power and signal cables must be routed together, keep the distance between them to a minimum. Keep in mind, however, that fiber optic cables are not affected by interference from electricity lines.

World of Controls has the most extensive range of Speedtronic Mark V control spare parts. World of Controls' experts are always available to help you with your GE Mark V requirements. Please contact us if you require any other information.



FREQUENTLY ASKED QUESTIONS



What is DS200TCTSG1AFE?

DS200TCTSG1AFE is a simplex trip board under the Mark V series.

Which are the connectors included in DS200TCTSG1AFE?

The GE Simplex Trip Board DS200TCTSG1AFE has 12 plug-in relays. Three (16-pin) and two (12-pin) connectors are also included. The 16-pin connectors are assigned the IDs JDR, JDS, and JDT. The IDs for the 12-pin connectors are JN and JM.

How to obtain DS200TCTSG1AFE?

Call or mail the World of Controls team. WOC provides DS200TCTSG1AFE boards and other turbine control components.
