330101-00-12-10-02-00 - PROBE PROXIMITY SENSOR 3300XL 8MM

330101-00-12-10-02-00 - PROBE PROXIMITY SENSOR 3300XL 8MM 330101-00-12-10-02-00 - PROBE PROXIMITY SENSOR 3300XL 8MM

World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.

330101-00-12-10-02-00 - PROBE PROXIMITY SENSOR 3300XL 8MM is available in stock which ships the same day.

330101-00-12-10-02-00 - PROBE PROXIMITY SENSOR 3300XL 8MM comes in UNUSED as well as REBUILT condition.

To avail our best deals for 330101-00-12-10-02-00 - PROBE PROXIMITY SENSOR 3300XL 8MM, contact us and we will get back to you within 24 hours.

SPECIFICATIONS

Part Number: 330101-00-12-10-02-00
Manufacturer: Bently Nevada
Product Type: 3300 XL 8 mm Proximity Probe
Availability: In Stock
Country of Origin: United States(USA)

330101-00-12-10-02-00 is a 3300 XL 8 mm Proximity Probe manufactured by Bently Nevada and used in Proximity Transducer System. In direct proportion to the separation between the probe tip and the detected conductive surface, the system outputs a voltage. It is primarily utilized for vibration and position measurement applications on fluid-film bearing machines, as well as Keyphasor and speed measurement applications, and is capable of both static (position) and dynamic (vibration) measurements.

Functional Description

  • 3300 XL 8 mm system has the most cutting-edge performance in an eddy current proximity transducer system. The standard API 670 Standard (4th Edition) for mechanical configuration, linear range, precision, and temperature stability is also fully met by the standard 3300 XL 8 mm 5 meter system.
  • The total interchangeability of the probe, extension cable and Proximitor Sensor in all 3300 XL 8 mm Proximity Transducer Systems enables this level of performance without the requirement for bench calibration or individual component matching.
  • Additionally, connection guards can be purchased pre-installed on 3300 XL 8 mm Probes and Extension Cables. For installation in the field, connector shields can also be provided separately (such as when the cable must be run through a restrictive conduit). All installations should include connector protectors since they promote environmental protection.

330101-00-12-10-02-00 Features

  • Unthreaded Length Option : 0.0 in
  • Overall Case Length Option : 1.2 in
  • Total Length Option : 1.0 metre (3.3 feet)
  • Connector and Cable-Type Option : Miniature coaxial ClickLocTM connector, standard cable
  • Agency Approval Option : Not required
  • Weight : 0.323 Kg

World of Controls has the most comprehensive catalog of Bently Nevada Replacement parts. Our professionals are standing by to help you with your needs. If you require any additional information, please contact WOC.


FREQUENTLY ASKED QUESTIONS



What is Bently Nevada 330101-00-12-10-02-00?

330101-00-12-10-02-00 is a 3300 XL 8 mm Proximity Probe used in Proximity Transducer System.
